Installing a Red Hat OpenShift cluster on Oracle Cloud Infrastructure

Learn how to quickly deploy your OpenShift cluster on OCI using the Assisted Installer

Download Terraform stacks

OpenShift cluster creation on Oracle Cloud Infrastructure - Releases · oracle-quickstart/oci-openshift

Releases · oracle-quickstart/oci-openshift

Generate ISO

Log In | Red Hat IDP

Hybrid Cloud Console Home | Home

Overview | OpenShift

Create an OpenShift cluster | Red Hat OpenShift Cluster Manager

Install OpenShift 4 | Red Hat OpenShift Cluster Manager | Oracle Cloud Infrastructure

Oracle Cloud Infrastructure (Requires a custom manifest)
Learn more

Create the infrastructure on OCI

Oracle Cloud Infrastructure | Sign In

Cloud Sign In

Home | Oracle Cloud Infrastructure

Buckets | Oracle Cloud Infrastructure

Show Optional Response Headers and Metadata

c0c90fef-1e09-4837-a42b-e028f4219e69-discovery.iso
	Wed, Jul 9, 2025, 15:46:26 UTC	124.53 MiB	Standard

Home
Compute
Storage
Networking
Oracle Database
Databases
Analytics & AI
Developer Services
Identity & Security
Observability & Management
Hybrid
Migration & Disaster Recovery
Billing & Cost Management
Governance & Administration
Marketplace

A stack is a Terraform configuration that you can use to provision and manage your OCI resources. To provision the resources defined in your stack, apply the configuration.

Choose the origin of the Terraform configuration. The Terraform configuration outlines the cloud resources to provision for this stack. Learn more
 My configuration

Upload Terraform configuration files.

 Template

Select an Oracle-provided template or private template.

 Source code control system

Select a Terraform configuration from Bitbucket Cloud, Bitbucket Server, DevOps, GitHub, or GitLab.

 Existing compartment

Create a stack that captures resources from the selected compartment (resource discovery).

Stack configuration
More information
Terraform configuration source
 Folder
 Object Storage bucket
 .Zip file
 Drop a .zip file.
 Browse
create-resource-attribution-tags-v1.3.0.zip
Stack information
OpenShift on OCI Resource Attribution Tags
Working directory
Use Terraform configuration files in the root folder
The file path to the directory from which to run Terraform
Custom providers
 Use custom Terraform providers
Store custom Terraform providers in a bucket.
Name
Optional
Description
Optional
Create in compartment
mak-testing
rhelcert (root)/mak-testing
Terraform version
1.5.x
Review the list of Terraform versions supported by Resource Manager.
Tags
Add tags to organize your resources. What can I do with tagging?
Tag namespace
None (add a free-form tag)
benny
CloudMigrations
ocodfcnv
ocp-edge-ci-phase3-oci-sdn-4-14-0
openshift
openshift-adg
openshift-ci-op-34gfbwhm-127b6
openshift-ci-op-96ng8sv2-02352
openshift-ci-op-cmsn6dxx-36f59
openshift-ci-op-djpylywy-127b6
openshift-ci-op-q4mhtt0c-127b6
openshift-ci-op-qz7dxhi3-13734
openshift-ci-op-s7lb9fk4-56696
openshift-cicd
openshift-e2e-runs
openshift-example
openshift-javipolo
openshift-javipolo-claude
openshift-mmaciktest
openshift-myarmcluster
openshift-mycluster
openshift-oci-asvqkfth
openshift-oci-axbomfbm
openshift-oci-bzfesqpt
openshift-oci-dsfpydcb
openshift-oci-eigyzdln
openshift-oci-geeialjk
openshift-oci-iahtlnoq
openshift-oci-irfnydpc
openshift-oci-irnyucub
openshift-oci-ividxcfu
openshift-oci-khuawdmn
openshift-oci-kpjsbypx
openshift-oci-rhmmmthz
openshift-oci-vdpa-test-0324-1509
openshift-oci-vdpa-test-0324-1620
openshift-oci-vdpa-test-0324-2050
openshift-oci-vdpa-test-0324-2320
openshift-oci-vdpa-test-0325-1840
openshift-oci-vyggttli
openshift-oci-wlqqqzpj
openshift-oci-xxezxdsd
openshift-oci-zrxymkto
openshift-ocp-edge-ci-phase3-oci-sno-4-19-0
openshift-ocp-virt-abi-bm
openshift-oso459test7
openshift-resource
openshift-spoke-0
openshift-tags-dfoster
openshift-test-david-oci-r238rk2
openshift-test-infra-cluster-e8269a08
openshift-vdpa-test
openshift-vdpa-test-oci
openshift-vdpa-test-oci-0324
openshift-vdpa-test-oci-0324-1925
openshift-vdpa-test-oci-0325-0925
openshift-vdpa-test-oci-0325-1200
openshift-vdpa-test-oci-0325-1320
openshift-vdpa-test-oci-0325-1445
openshift-vdpa-test-oci-0325-1840
openshift-vdpa-test-oci-0325-2100
openshift-vdpa-test-oci-0325-2240
openshift-vdpa-test-oci-0325-2330
openshift-vdpa-test-oci-0326
openshift-vdpa-test-oci-0326-1000
openshift-vdpa-test-oci-0326-1110
openshift-vdpa-test-oci-0326-1621
openshift-vdpa-test-oci-1840
openshift-vdpa-test-oci-21
openshift-vdpa-test-oci-26
openshift-vinayakbtest0702-2
openshift-vinayakbyon2306
openshift-vlad
Oracle-Tags
rajat-e2e
test-1
Tag key
Tag value
Remove row
Add tag

Jobs | Oracle Cloud Infrastructure

Cluster Name
(Required) - The name of your OpenShift cluster. It should be the same as what was specified when creating the OpenShift ISO and it should be DNS compatible. The cluster_name value must be 1-54 characters. It can use lowercase alphanumeric characters or hyphen (-), but must start and end with a lowercase letter or a number.
This variable is required.

OpenShift Image Source URI
(Required) - The OCI Object Storage URI for the OpenShift image. Before provisioning resources through this Resource Manager stack, users should upload the OpenShift image to OCI Object Storage, create a pre-authenticated requests (PAR) uri, and paste the uri to this block. For more details, review Object Storage and PARs.
This variable is required.

Tag Namespace Compartment For OpenShift Resource Attribution Tags
(Required) - WARNING - Please make sure this tag exists before you apply the terraform stack. The compartment where the tag namespace for resource tags should be created. Defaults to current compartment. The tag namespace and defined tags for OpenShift Attribution on OCI resources will be `openshift-tags` and `openshift-resource`. If this namespace already exists, the field should be verified to ensure it is correctly defined and applied. Example --> "defined-tags" - {"openshift-tags"- {"openshift-resource" - "openshift-resource-infra"} }

Enable Public API Load Balancer
Create a Load Balancer for the OpenShift API endpoint (`api.<cluster>.<base_domain>`) in the public subnet with a public IP address. This allows users and administrators to access the OpenShift control plane over the internet. If disabled, the API Load Balancer will be created in a private subnet with a private IP, limiting access to within the VCN or through a connected VPN/private network. Public API access is useful for remote cluster management, automation, and CI/CD pipelines. In on-premise environments (e.g., C3/PCA), "public" IPs may refer to RFC 1918 addresses that are only routable within your internal network. Consult your network administrator to confirm external access.

Create Private DNS
Create a private DNS zone with your Base domain specified in Zone DNS. It will contain the same records as a public DNS zone and will facilitate the cluster's hostname resolution within the VCN. If using an unregistered domain name as the Base domain for your cluster, you should create a private DNS zone if possible, or you will have to take other measures to help the instances resolve the cluster's hostname. For more details, review Oracle Private DNS
